TRANSIENT VOLTAGE SUPPRESSOR POWER 400 Watt
BREAK DOWN VOLTAGE
6.8 to 550 Volt
DO-41
Unit:mm
FEATURES
• Glass passivated junction
• Low inductance
• Plastic Material has UL Flammability Classification 94V-O
• Fast response time: typically less than 1.0ps from 0V to BV min
• High temperature soldering : 260°C /10 seconds at terminals
• ESD IEC-61000-4-2 Air ±30kV, Contact ±30kV
• Lead free in compliance with EU RoHS 2.0
MECHANICAL DATA
• Case: Molded plastic over passivated junction.
• Polarity: Color band denotes cathode end
P4KE6.8A P4KE6.8CA
P4KE7.5A P4KE7.5CA
P4KE8.2A P4KE8.2CA
P4KE9.1A P4KE9.1CA
P4KE10A P4KE10CA
P4KE11A P4KE11CA
P4KE12A P4KE12CA
P4KE13A P4KE13CA
P4KE15A P4KE15CA
P4KE16A P4KE16CA
P4KE18A P4KE18CA
P4KE20A P4KE20CA
P4KE22A P4KE22CA
P4KE24A P4KE24CA
P4KE27A P4KE27CA
P4KE30A P4KE30CA
P4KE33A P4KE33CA
P4KE36A P4KE36CA
P4KE39A P4KE39CA
P4KE43A P4KE43CA
P4KE47A P4KE47CA
P4KE51A P4KE51CA
P4KE56A P4KE56CA
P4KE62A P4KE62CA
P4KE68A P4KE68CA
P4KE75A P4KE75CA
P4KE82A P4KE82CA
P4KE91A P4KE91CA
P4KE100A P4KE100CA
P4KE110A P4KE110CA
P4KE120A P4KE120CA
P4KE130A P4KE130CA
P4KE150A P4KE150CA
P4KE160A P4KE160CA
P4KE170A P4KE170CA
P4KE180A P4KE180CA
P4KE200A P4KE200CA
P4KE220A P4KE220CA
P4KE250A P4KE250CA
P4KE300A P4KE300CA
P4KE350A P4KE350CA
P4KE400A P4KE400CA
P4KE440A P4KE440CA
P4KE480A P4KE480CA
P4KE510A P4KE510CA
P4KE530A P4KE530CA
P4KE540A P4KE540CA
P4KE550A P4KE550CA
