SMALL SIGNAL SCHOTTKY BARRIES SWITCHING DIODES
LMSD103A
LMSD103B
LMSD103C
|
MICRO-MELF |
Unit : inch (mm) |
|
.040(1.0) .048(1.2)DIA. .043(1.1) .008(0.2) .008(0.2) .079(2.0) .071(1.8) |
|
VOLTAGE
20 to 40 Volts
CURRENT
0.35 Amperes
• • • •
FEATURES
• Low Forward Voltage Drop
• Guard Ring Construction for Transient Protection
• Low Reverse Recovery Time
• Low Reverse Capacitance
• In compliance with EU RoHS 2002/95/EC directives
MECHANICAL DATA
Case: Molded Glass MICRO-MELF
Terminals: Solderable per MIL-STD-750, Method 2026 Polarity: See Diagram Below
Mounting Position: Any
