SILICON ZENER DIODE
FEATURES
- Low inductance
- High temperature soldering : 260°C /10 seconds at terminals
- Glass package has Underwriters Laboratory Flammability Classification
- Lead free in compliance with EU RoHS 2011/65/EU directiveMECHANICAL DATA
- Case: Molded Glass DO-41G
- erminals: Axial leads, solderable per MIL-STD-750, Method 2026
- olarity: Color band denotes positive end
- eight: 0.012 ounce, 0.317 gram
- Marking:Type Number
|
1N6485 |
3.3 |
3.14 |
3.47 |
10 |
76 |
400 |
1 |
100 |
|
1N6486 |
3.6 |
3.42 |
3.78 |
10 |
69 |
400 |
1 |
100 |
|
1N6487 |
3.9 |
3.71 |
4.1 |
9 |
64 |
400 |
1 |
50 |
|
1N6488 |
4.3 |
4.09 |
4.52 |
9 |
58 |
400 |
1 |
10 |
|
1N6489 |
4.7 |
4.47 |
4.94 |
8 |
53 |
500 |
1 |
10 |
|
1N6490 |
5.1 |
4.85 |
5.36 |
7 |
49 |
550 |
1 |
10 |
|
1N6491 |
5.6 |
5.32 |
5.88 |
5 |
45 |
600 |
1 |
10 |
|
1N4460 |
6.2 |
5.89 |
6.51 |
2 |
41 |
700 |
1 |
10 |
|
1N4461 |
6.8 |
6.46 |
7.14 |
3.5 |
37 |
700 |
1 |
5 |
|
1N4462 |
7.5 |
7.13 |
7.88 |
4 |
34 |
700 |
0.5 |
5 |
|
1N4463 |
8.2 |
7.79 |
8.61 |
4.5 |
31 |
700 |
0.5 |
5 |
|
1N4464 |
9.1 |
8.65 |
9.56 |
5 |
28 |
700 |
0.5 |
0.5 |
|
1N4465 |
10 |
9.5 |
10.5 |
7 |
25 |
700 |
0.25 |
0.5 |
|
1N4466 |
11 |
10.45 |
11.55 |
8 |
23 |
700 |
0.25 |
0.1 |
|
1N4467 |
12 |
11.4 |
12.6 |
9 |
21 |
700 |
0.25 |
0.1 |
|
1N4468 |
13 |
12.35 |
13.65 |
10 |
19 |
700 |
0.25 |
0.1 |
|
1N4469 |
15 |
14.25 |
15.75 |
14 |
17 |
700 |
0.25 |
0.1 |
|
1N4470 |
16 |
15.2 |
16.8 |
16 |
15.5 |
700 |
0.25 |
0.1 |
|
1N4471 |
18 |
17.1 |
18.9 |
20 |
14 |
750 |
0.25 |
0.1 |
|
1N4472 |
20 |
19 |
21 |
22 |
12.5 |
750 |
0.25 |
0.1 |
|
1N4473 |
22 |
20.9 |
23.1 |
23 |
11.5 |
750 |
0.25 |
0.1 |
|
1N4474 |
24 |
22.8 |
25.2 |
25 |
10.5 |
750 |
0.25 |
0.1 |
|
1N4475 |
27 |
25.65 |
28.35 |
35 |
9.5 |
750 |
0.25 |
0.1 |
|
1N4476 |
30 |
28.5 |
31.5 |
40 |
8.5 |
1000 |
0.25 |
0.1 |
|
1N4477 |
33 |
31.35 |
34.65 |
45 |
7.5 |
1000 |
0.25 |
0.1 |
|
1N4478 |
36 |
34.2 |
37.8 |
50 |
7 |
1000 |
0.25 |
0.1 |
|
1N4479 |
39 |
37.05 |
40.95 |
60 |
6.5 |
1000 |
0.25 |
0.1 |
|
1N4480 |
43 |
40.85 |
45.15 |
70 |
6 |
1500 |
0.25 |
0.1 |
|
1N4481 |
47 |
44.65 |
49.35 |
80 |
5.5 |
1500 |
0.25 |
0.1 |
|
1N4482 |
51 |
48.45 |
53.55 |
95 |
5 |
1500 |
0.25 |
0.1 |
|
1N4483 |
56 |
53.2 |
58.8 |
110 |
4.5 |
2000 |
0.25 |
0.1 |
|
1N4484 |
62 |
58.9 |
65.1 |
125 |
4.0 |
2000 |
0.25 |
0.1 |
|
1N4485 |
68 |
64.6 |
71.4 |
150 |
3.7 |
2000 |
0.25 |
0.1 |
|
1N4486 |
75 |
71.25 |
78.75 |
175 |
3.3 |
2000 |
0.25 |
0.1 |
